Features

WELDING DIAMETER 1-12″  (25-305 mm)  ·  GMAW AND FCAW  ·  300 A AT 100% DUTY

Welding diameter 1-12″  (25-305 mm)|
Processes GMAW, FCAW with gas shield
Current rating 0-300 amps at 100% duty cycle
Rotation speed 0.5-6.0 rpm
Rise and fall cam 0-5″  (0-127 mm)
Input voltage 115 VAC from the welder
Welding voltage 0-50 VAC
Spool capacity 30 lbs  (14 kg), wire reel adaptor included
Shielding gas Solenoid controlled
Cables supplied 50 ft (15 m) gas hose, weld cable and control cable
Cable handling No wrap-up or tangling regardless of direction of rotation
Mounting Carriage or monorail
Control Burn back control; horizontal and vertical gun and cable adjustment
Carriages CWO-4530 with lever · CWO-4540 with winch · CWO-4550 with motorised lift
Accessories CWO-3023-1 torch angle adjuster · CWO-5790 cone adaptor, 1¼-4″ (32-102 mm) · CWO-3670 step adaptor for threaded outlets, ½-4″ (13-102 mm) · CWO-3675 groove adaptor · CWO-3894 hillside kit · KBUG-5050 stand alone weaver
Bug-O item number CWO-1500-MG
