Compact Edge

General Information

Range w.t. 6-60 mm (1/4'' – 2 3/8'')

Brand new plate beveling machine Compact EDGE, featuring a high speed milling head with interchangeable inserts, with reduced structural dimensions and weight for a more flexible and dynamic use.

The feeding system has been completely revised, the overall dimensions have been reduced and the transmission quality has been improved by using a single motor of traction.

The machine is equipped with a stepless variable head type which allows bevel angles from 15° to 60°, granting a very easy and quick adjustment of the angle of bevel.

 The machine is equipped with a plate detecting sensor and trolley with a new chips conveyance system. We have also implemented a dual amortization system which allows to overcome eventual imperfections of the wall thickness or eventual variations of the plate, as well as the imperfections of the ground.

RANGE:
 1/4” to 2 3/8 ” thickness

FUNCTIONS:
 bevel from 15° to 60°.

MATERIALS:
 carbon steel, stainless steel, duplex, super duplex, inconel, aluminium, etc.

POWER:
 electric 3 phase 400V 50Hz

NOTE:
 It can bevel any material with smooth surface finishing, groove free. The feeding system with adjustable speed allows the unit to be used without the help of cranes or lifting devices.
