800SA
Standard Features
Double column machine provides maximum capacity and rigidity
Design utilizes linear bearings for high stiffness and smooth motion
Hydraulic tensioning of 2-5/8" band saw blade
Hydraulic lift of the saw head
Saw up travel can be set to minimize distance between the blade and the top of the material
Saw down travel can be set to allow notching of blocks
Semi-automatic cut cycle and manual saw control, saw up, rapid saw down, saw cut
Cutting feed rate hydraulically adjusted
Load sensing valve stops the feed if the blade starts to overload, typical cutting structural shapes
Magnetic motor starter with automatic shut off at the end of cut, motors thermal overload protection
Blade speed controlled by a variable frequency drive
Lockable power disconnect on machine
Blade guards
Powered blade brush to remove cutting chips
Split vise design clamps material on both side of blade
Infeed conveyor and material discharge conveyor
Alarms for broken blade / under tension and doors open
Steel wheels with ductile iron hubs
Blade guides are carbide faced with rollers to remove blade twist and dampen vibration
Flood coolant system to both saw guides and a adjustable nozzle mounted on stationary vise, all with adjustable flow rates
Gear box designed for heavy duty band saw machines, high efficiency planetary gear system
All ball bearings are totally enclosed and lubricated for life
Electric system uses only C.S.A./UL approved components.
Premium quality bimetal band saw blade
Instruction and parts manual
