600M2
Standard Features
Double column machine provides maximum capacity and rigidity.
Miter cutting to the front 45° and rear 60°.
Hydraulic tilt of saw head with digital display with preset pause.
Tilt has variable speed to aid in accurate positioning.
Blade canted at 4 degrees to aid in cutting structural steel and flats.
Design utilizes linear bearings for high stiffness and smooth motion.
Stationary front and rear horizontal vises.
Full stroke hydraulic vises on both sides of the blade with variable vise pressure.
Hydraulic lift of the saw head.
Saw up travel can be set to minimize distance between the blade and the top of the material.
Saw down travel limit can be set.
Cutting feed rate hydraulically adjusted.
Rapid down to prevent unnecessary adjustment of the feed rate.
Load sensing valve stops the feed if the blade starts to overload, typical when cutting the web of structural shapes.
Steel wheels with ductile iron hubs.
Blade guides are carbide faced with rollers to remove blade twist and dampen vibration.
Flood coolant system to both saw guides with adjustable flow rates.
Gearbox designed for heavy-duty band saw machines, high efficiency planetary drive, oil bath lubrication.
Control panel mounted on pivot to aid operator positioning.
Electric system uses only C.S.A./UL approved components and is electrically approved.
Premium quality bimetal band saw blade
Instruction and parts manual
