475M
Standard Features
Double column machine provides maximum capacity and rigidity
Blade angle is at 4° from the horizontal which assists in the cutting of large sections and structural profiles
Hydraulic lift of the saw head
Hydraulic full stroke vise
Hydraulic miter of saw head with digital display of angle
Design utilizes linear bearings for high stiffness and smooth motion
Electronic variable speed
Blade breakage and open door automatic shut off with alarm indicator
Saw up travel can be set to minimize distance between the blade and the top of the material
Semi-automatic cut cycle
Manual saw control, saw up, rapid saw down, saw cut
Cutting feed rate hydraulically adjusted with Load sensing valve stops the feed if the blade starts to overload
Power disconnect on machine
Powered blade brush to remove cutting chips
Blade guides are carbide faced with rollers to remove blade twist and dampen vibration
Flood coolant system to both saw guides with adjustable flow rates
Direct blade drive using a planetary gear box for a high efficiency design
Electric system uses only C.S.A./UL approved components and is electrically approved
Premium quality bimetal band saw blade
Instruction and parts manual
