360SA
Standard Features
Double column machine provides maximum capacity and rigidity
Design utilizes linear bearings for high stiffness and smooth motion
Hydraulic lift of the saw head
Saw up travel can be set to minimize distance between the blade and the top of the material
Saw down travel can be set to allow notching of blocks
Semi-automatic cut cycle and manual saw control, saw up, rapid saw down, saw cut
Cutting feed rate hydraulically adjusted
Load sensing valve stops the feed if the blade starts to overload, typical cutting structural shapes
Magnetic motor starter with automatic shut off at the end of cut, motors thermal overload protection
Power disconnect on machine
Blade guards and fully enclosed drive belt guard
Powered blade brush to remove cutting chips
Quick acting material clamping
Miter cuts up to 45 degrees by swiveling vise
Adjustable material length stop for repetitive cutting
Cast ductile iron wheel
Blade guides are carbide faced with rollers to remove blade twist and dampen vibration
Flood coolant system to both saw guides with adjustable flow rates
Gear box designed for heavy duty band saw machines, precision worm shaft on taper roller bearings and phosphorous bronze worm gear set supported on sealed ball bearings, oil bath lubrication
All bearings are totally enclosed and lubricated for life
Electric system uses only C.S.A./UL approved components and is electrically approved
Premium quality bimetal band saw blade
Instruction and parts manual
