300V Vertical Band Saw
Standard Features
Blade is oriented vertically
Machine movement is on linear bearing to provide maximum rigidity and smooth motion
The saw head feed utilizes a load sensing valve which stops the feed if the blade starts to over-load, typical when cutting the web of structural shapes
Blade Guides are carbide faced with roller to remove blade twist and dampen vibration
Magnetic motor starter with automatic shut off at the end of cut, motors thermal overload protection
Blade is preloaded to optimize cutting
Blade tension is adjusted manually
Blade drive system consists of a direct drive, high efficiency planetary geardrive
Blade speed con-trolled with a variable frequency drive
Manual saw forward, saw retract, saw cut, vise open/closed
Controls are to the rear of the machine
Blade breakage switch
Ductile iron wheels
Mist coolant system
Electrical system uses only C.S.A./UL approved components and is electrically approved
Premium quality bimetal band saw blade
Instruction and parts manual
